GauthierDeLaPlante offers a wide selection of hardware for cable railing projects. Our products are made of top quality 316 stainless steel and are suitable for both indoor and outdoor projects.
4 easy steps
1 - Determine the # of sections (between 2 end posts)
2 - Determine the # of cable runs
3 - Choose the fasteners and tensioners
4 - Select the quantity of posts and total length of handrail
1 – Determine the # of sections (between 2 end posts)
A tensioner set allows a cable run to be tensioned between 2 end posts. The cable passes through the intermediate posts. Depending on the types of tensioners chosen, it is possible to make sections of up to 60 feet.
Some patios may have more sections depending on their design. In many cases, there are stairs. Here is another common example of a structure that has multiple sections.
Structure with 6 sections : 4 straight + 2 oblique (stairs)
2 – Identify the number of cable runs
For greater safety and aesthetic, we recommend installing a cable run every 4 inches. If your railing is installed on a structure less than 6 feet, the height of the railing must be 36” high. If your railing is installed on a structure over 6 feet, the height of the railing must be 42” high.
Railing at 36’’: 7-8 cable runs
Railing at 42’’: 9-10 cable runs
3 - Choosing the fasteners and tensioners
Select a set according to your budget or desired design. The top 3 sets make straight lines exclusively. The bottom 4 sets can make straight lines and stairs.
Here is how to calculate the costs for a patio of 3 straight sections totaling 44 linear feet. You choose the $22.99 Swageless threaded stud cable railing system
- 3 sections x 8 cable runs = 24 kits = $551.76
- 8 cable runs x 44 linear feet (LF) = 352 LF x .67$/LF = 235,84$
- Total cable and tensioners: $787,60
4 – Select the quantity of posts and total length of handrail
End posts must be firmly anchored in your structure. The turnbuckles and fasteners will be attached to these posts and they will be subjected to a tension of more than 220 lbs (100 kg). We recommend at least 1’’½ x 1’’½ posts.
The intermediate posts are essentially used to support the handrail and to keep the cable on a perfectly straight line. It is recommended to install intermediate posts every 48”.
The handrail helps to maintain the integrity of the structure and must be installed before the tensioning the stainless steel wire rope. The handrail can be made of wood or metal. We offer a 2” x 1” powder coated aluminum handrail.
Here is how to calculate the costs for a patio with 12 posts and 44 linear feet of handrail:
- 12 painted aluminum posts, pre-drilled x $189.99 = $2279.88
- 44 linear feet of handrail x $20.99/PL = $923.56
- Total posts and handrail: $3203.44
